Kayak Anchor Trolley Kit Anchor Wizard Kayak Leverlock Anchor System for Kayak Canoes Boat
Description Part Number 1-89757aabbcc Item Package Dimensions L x W x H 9.8 x 7.99 x 2.56 inches Package Weight 0.52 Kilograms return Free Returns shipping Free Shipping

Anchor ring,pad eyes and carabiner of the kayak anchor trolley system are all made of 316 stainless steel,which is more anti-rust and wear resistance,strong and durable,enhance the stability and safety of the anchor trolley system.

30 Feet(9 meters) long,5 mm diameter strong paracord,Will not deform or break under severe weather and heavy-duty tasks,Also comes with rivets with washers,Used when you cannot touch the back of the fastener.

kayak trolley kit is equipped with two 5 mm diameter elastic rings,Install at the eye pad,It will help to dampen and absorb some of the kayak's movement when anchored in lively conditions,and it will also keep the anchor trolley line taut to the kayak hull.

Kayak anchor trolley system kit can be installed on left or right side,This kit uses a rope and pulley to help you shift the position of your vessel without pulling up your anchor,then maintains the positioning with a mini zigzag cleat,this way, the kayak is in the ideal position regardless of the current or wind direction.

Anchor Trolley Kit includes:1 pcs Paracord,1 pcs Rope Cleat,1 pcs Anchor Ring,2 pcs Pulley,2 pcs spring snap hook,2pcs Elastic Ring,4 pcs Pad Eyes,10 pcs Rivets,10 pcs Bolts,10 pcs Screws.

Product Description
QUICK TUPS Trolley system should not be spaced more than 14.5 feet from pulley to pulley .Installation does require the drilling of a number of holes in your boat, so proceed carefully and be sure of locations and access before drilling. Review the contents of the kit and read the instructions before doing anything to your kayak. These are basic guidelines that will allow you to understand the kit, but keep in mind that all kayaks are slightly different and you can customize your installation many ways. We provide a variety of fasteners.We recommend installing using either bolts/washers/nuts if you can access the rear of the area where you are fitting, if not then trifold rivets When you can not use the rivet gun, and without insede access. the self tapping screws can also work well. Use waterproof silicone in any holes you drill .
Pulleys - Snap Hook - Pad Eye
45 degree
Clinch Knot
Optional Bungee PULLEYS INSTRUCTIONS
: The pulley is fixed on kayak by Pan Eye and Snap Hook.
The standard location for the pulleys will be above the WATER LINE of the kayak,approximately 9-12 inches from the bow and stern.
This will enable the “pole-setting ring” to travel the entire length of the boat.
1.The first step is to fit the pad eyes at either end of the kayak. The pad eye will have a karabiner and pulley attached to it,which the trolley line will run between.We recommend the pad eye to be as close to the back as possible.
approximately 7-10 inches from the bow and stern.Once you find a good spot for the Pad Eyes,Mark the mounting hole.
Using the Bolts with a Washer and Nyloc Nut on the inside of the hull.use a 3/16 drill bit to make holes .if no inside access .use rivets (use 1/8" drill bit if using the screws),
after install pad eyes,used the Stainless Steel Karabiner to attach Pulley to the pad eyes.
2.Using other pan eyes as a guide for the trolley line : Pad eyes will help keep the trolley line in posit.Mount on edge similar to you installed the pulley.
How many you use is up to you,and depends on the length of the trolley and how well supported you want the line to be.
We recommend install pad eye 1/3 the distance from the rear and front of the kayak .
Make sure to angle the bottom of the pad eyes toward the center line of your boat .
This angle toward the middle of the boat helps prevent the rope from sagging.all holes pleas use silicone to make the holes waterproof.
-------- TROLLEY LINE INSTALLTION
: Feed the line up through the pulley on the bow, across and through the pad eyes and down through the other pulley on the stem.
Next,the two cord ends should be tied to the Pole Setting Ring to complete the trolley system(“Barrel” or “Clinch” knots are recommended ).
1.First, tie one of the loose cord ends directly to Pole Ring.
2.Then insert remaining loose cord end through ring and pull cord until desired amount of slack has been removed.
3.Once cord length for optimal system tension has been determined, leaving enough extra for later adjustments just in case.
4.Finally, trim off excess cord and singe ends with lighter or matches to prevent fraying.
------- NOTE
: Optional installation,The Anchor Trolley kit comes with a bungee cord .
This serves two purposes. It will help to dampen and absorb some of the kayak's movement when anchored in lively conditions, and it will also keep the anchor trolley line taut to the kayak hull.
This bungee cord loop can be passed through the bow pad eye and held in place against the eye by the plastic bead.
WITHOUT bungee cord will not affect the use of Anchor Trolley.
------- ZIG ZAG CLEAT lNSTALLATION
: The Zig-Zag cleat is provided to lock down the anchor’s position on your trolley system.
It also keeps the bottom trolley line in place so that it is easily accessible.
1.Placement of the zig zag deat needs to be on an easily accessible point from your paddling position.
Slightly behind the seat is generally preferred (versus directly beside seat) to minimize interference between cleat and paddle strokes.
Make sure cleat is within convenient reach from seat position.
2.Once the position is selected. Mark the mounting hole.
use a 3/16 drill bit to make holes.If no inside access .use rivets .
(use 1/8" drill bit if using the self tapping screws).
Apply waterproof silicon on the marks and on the back of the cleat.
